Imagine the frustration of a door that sticks or stutters as you try to open or close it. This common household annoyance often stems from something as simple as dirty or obstructed tracks. Ensuring your doors glide smoothly not only enhances the functionality of your home but also adds to its aesthetic appeal by eliminating the jarring sight of a struggling door. Lets delve into why maintaining clean tracks is essential and how to go about it effectively.


First, understanding why door tracks get dirty is key. Over time, dust, hair, small debris, and even tiny insects can accumulate in the grooves where doors slide. In environments with pets or high traffic, this problem can escalate quickly. Moreover, in humid climates or areas prone to moisture, rust and corrosion might begin to form on metal tracks, further impeding smooth movement.


The process of cleaning these tracks isnt just about restoring function; its also preventative maintenance. Regular cleaning prevents the accumulation of grime that could eventually lead to more significant issues like track damage or door misalignment. When a door operates smoothly, it reduces wear and tear on both the door itself and its hardware, extending the lifespan of your investment.


To start cleaning your door tracks, youll need some basic tools: a vacuum cleaner with a narrow attachment for initial debris removal, a soft brush (an old toothbrush works wonders), mild soap mixed with warm water in a spray bottle for lubrication and cleaning, dry cloths for wiping down, and optionally, a lubricant like silicone spray for metal tracks.


Begin by removing any large pieces of debris visible in the track with your fingers or tweezers. Then, use the vacuum cleaner to suck out finer particles that might be lurking deeper within the track. This step is crucial as it prevents pushing dirt around rather than removing it during the washing phase.


Next, spray your soapy solution into the track. Let it sit for a few minutes to loosen any stubborn grime. Use your brush to scrub along the length of the track gently but thoroughly. The goal here isnt just cleanliness but also ensuring no residue remains that could attract more dirt over time.


After scrubbing, wipe down the track with a dry cloth to remove soap residue and any remaining dirt. If youre dealing with metal tracks prone to rusting or sticking due to humidity, this is when youd apply a light coat of lubricant after drying. Silicone sprays are excellent because they dont collect dust like oil-based products might.


Finally, test your door by sliding it back and forth several times. This action helps ensure all parts are moving fluidly across freshly cleaned surfaces and distributes any applied lubricant evenly.


In conclusion, keeping door tracks clean is an often overlooked aspect of home maintenance that significantly impacts daily comfort and long-term durability. By dedicating some time periodically to this task, homeowners can enjoy seamless operation from their doors year-round. Not only does this practice save money by preventing premature wear but also contributes subtly yet effectively to maintaining an inviting atmosphere in ones living space where every detail works harmoniously together - even something as mundane as opening a door becomes effortlessly smooth again after cleaning those tracks properly!

Tightening Hardware to Reduce Door Noise

A coil spring is a mechanical tool that usually is made use of to keep power and ultimately launch it, to absorb shock, or to maintain a pressure between contacting surfaces. It is constructed from an elastic material developed into the shape of a helix that goes back to its natural length when unloaded. Under stress or compression, the product (cable) of a coil springtime undergoes torsion. The spring characteristics as a result rely on the shear modulus. A coil spring may likewise be utilized as a torsion spring: in this case the springtime all at once goes through torsion concerning its helical axis. The product of the spring is consequently based on a bending minute, either reducing or boosting the helical span. In this mode, it is the Young's modulus of the material that establishes the springtime qualities.

.

Crown Factor is a city in and the area seat of Lake Area, Indiana, United States. The population was 34,884 per the 2023 American Community Survey. The city was included in 1868. On October 31, 1834, Solon Robinson and his household ended up being the very first settlers to an area that later on ended up being Crown Factor. Due to its area, Crown Point is known as the "Hub of Lake County". The city is surrounded by Merrillville to the north, Winfield to the eastern, Cedar Lake to the southwest, St. John to the west, and unincorporated Schererville to the northwest. The southerly and southwestern parts of Crown Point border some unincorporated areas of Lake Area.

.



A telephone keypad using the ITU E.161 standard.
Numeric keypad, integrated with a computer keyboard
A calculator
1984 flier for projected capacitance keypad

A keypad is a block or pad of buttons set with an arrangement of digits, symbols, or alphabetical letters. Pads mostly containing numbers and used with computers are numeric keypads. Keypads are found on devices which require mainly numeric input such as calculators, television remotes, push-button telephones, vending machines, ATMs, point of sale terminals, combination locks, safes, and digital door locks. Many devices follow the E.161 standard for their arrangement.

Uses and functions

[edit]

A computer keyboard usually has a small numeric keypad on the side, in addition to the other number keys on the top, but with a calculator-style arrangement of buttons that allow more efficient entry of numerical data. This number pad (commonly abbreviated to numpad) is usually positioned on the right side of the keyboard because most people are right-handed.

Many laptop computers have special function keys that turn part of the alphabetical keyboard into a numerical keypad as there is insufficient space to allow a separate keypad to be built into the laptop's chassis. Separate external plug-in keypads can be purchased.

Keypads for the entry of PINs and for product selection appear on many devices including ATMs, vending machines, point of sale payment devices, time clocks, combination locks and digital door locks.

Keypad technologies

[edit]

Apart from mechanical keypads,[1][2][3] there are a wide range of technologies that can be used as keypads, each with distinctive advantages and disadvantages. These include Resistive,[4] Capacitive,[5] Inductive,[6] Piezoelectric,[7] and Optical.[8]

Key layout

[edit]

The first key-activated mechanical calculators and many cash registers used "parallel" keys with one column of 0 to 9 for each position the machine could use. A smaller, 10-key input first started on the Standard Adding Machine in 1901.[9] The calculator had the digit keys arranged in one row, with zero on the left, and 9 on the right. The modern four-row arrangement debuted with the Sundstrand Adding Machine in 1911.[10]

There is no standard for the layout of the four arithmetic operations, the decimal point, equal sign or other more advanced mathematical functions on the keypad of a calculator.

The invention of the push-button telephone keypad is attributed to John E. Karlin, an industrial psychologist at Bell Labs in Murray Hill, New Jersey.[11][12] On a telephone keypad, the numbers 1 through 9 are arranged from left to right, top to bottom with 0 in a row below 789 and in the center. Telephone keypads also have the special buttons labelled * (star) and # (octothorpe, number sign, "pound", "hex" or "hash") on either side of the zero key. The keys on a telephone may also bear letters which have had several auxiliary uses, such as remembering area codes or whole telephone numbers.

The layout of calculators and telephone number pads diverged because they developed at around the same time. The phone layout was determined to be fastest by Bell Labs testing for that application, and at the time it controlled all the publicly connected telephones in the United States.

Origin of the order difference

[edit]

Although calculator keypads pre-date telephone keypads by nearly thirty years, the top-to-bottom order for telephones was the result of research studies conducted by a Bell Labs Human Factors group led by John Karlin. They tested a variety of layouts including a Facit like the two-row arrangement, buttons in a circle, buttons in an arc, and rows of three buttons.[11] The definitive study was published in 1960: "Human Factor Engineering Studies of the Design and Use of Pushbutton Telephone Sets" by R. L. Deininger.[13][14] This study concluded that the adopted layout was best, and that the calculator layout was about 3% slower than the adopted telephone keypad.

Despite the conclusions obtained in the study, there are several popular theories and folk histories explaining the inverse order of telephone and calculator keypads.

  • One popular theory suggests that the reason is similar to that given for the QWERTY layout, the unfamiliar ordering slowed users to accommodate the slow switches of the late 1950s and early 1960s.[15]
  • Another explanation proposed is that at the time of the introduction of the telephone keypad, telephone numbers in the United States were commonly given out using alphabetical characters for the first two digits. Thus 555-1234 would be given out as KL5-1234. These alpha sequences were mapped to words. "27" was given out as "CRestview", "28" as "ATwood", etc. By placing the "1" key in the upper left, the alphabet was arranged in the normal left-to-right descending order for English characters. Additionally, on a rotary telephone, the "1" hole was at the top, albeit at the top right.

Keypad track design

[edit]
Figure 1. Keypad wiring methods: separate connections (left), x/y multiplexing (center), Charlieplexing (right).

Separate connections

[edit]

A mechanically-switched 16-key keypad can be connected to a host through 16 separate connecting leads, plus a ground lead (Figure 1, left). Pressing a key will short to ground, which is detected by the host. This design allows any number or combination of keys can be pressed simultaneously. Parallel-in serial-out shift registers may be used to save I/O pins.

X/Y multiplexing

[edit]

These 16 + 1 leads can be reduced to just 8 by using x/y multiplexing (Figure 1, center). A 16-key keypad uses a 4 × 4 array of 4 I/O lines as outputs and 4 as inputs. A circuit is completed between an output and an input when a key is pressed. Each individual keypress creates a unique signal for the host. If required, and if the processor allows, two keys can be pressed at the same time without ambiguity. Adding diodes in series with each key prevents key ghosting, allowing multiple simultaneous presses.

Charlieplexing

[edit]

8 leads can detect many more keys if tri-state multiplexing (Figure 1, right) is used instead, which enables (n-1) × (n/2) keys to be detected with just n I/O lines. 8 I/O can detect 28 individual keys without ambiguity. Issues can occur with some combinations if two keys are pressed simultaneously. If diodes are used, then the number of unique keys detectable is doubled.[16]

See also

[edit]
  • Arrow keys
  • Charlieplexing
  • Digital door lock
  • Keyboard (computing)
  • Keyboard matrix circuit
  • Keyboard technology
  • Key rollover
  • Mobile phone
  • Numeric keypad
  • Push-button telephone
  • Rotary dial
  • Silicone rubber keypad
  • Telephone keypad

References

[edit]
  1. ^ "Mechanical keypad". Retrieved 2023-12-17.
  2. ^ "Mechanical keypads". Retrieved 2023-12-17.
  3. ^ "Mechanical push-button keypad". Retrieved 2023-12-17.
  4. ^ "Resistive membrane keypad" (PDF). Retrieved 2023-12-19.
  5. ^ "Capacitive keypads". Retrieved 2023-12-17.
  6. ^ "Inductive keypads" (PDF). Retrieved 2023-12-17.
  7. ^ "Piezo keypads". Retrieved 2023-12-17.
  8. ^ "Optical keypads". Retrieved 2023-12-17.
  9. ^ "William and Hubert Hopkins machines". Retrieved 2017-07-18.
  10. ^ "Sundstrand Adding Machine - Underwood Sundstrand". Retrieved 2017-07-18.
  11. ^ a b Fox, Margalit (2013-02-08). "John E. Karlin, Who Led the Way to All-Digit Dialing, Dies at 94". The New York Times. Retrieved 2013-02-09.
  12. ^ "Monmouth man, inventor of touch-tone keypad, dies at 94". The Star-Ledger. 2013-02-09. Archived from the original on 2013-02-13. Retrieved 2013-02-09.
  13. ^ Deininger, R. L. (July 1960). "Human Factor Engineering Studies of the Design and Use of Pushbutton Telephone Sets" (PDF). The Bell System Technical Journal. 39: 995. doi:10.1002/j.1538-7305.1960.tb04447.x. Archived from the original (PDF) on 2014-01-24. Retrieved 2014-02-07.
  14. ^ Feldman, Dave (1987). Why Do Clocks Run Clockwise. New York, USA: Harper & Row.
  15. ^ "Why is the keypad arrangement different for a telephone and a calculator?". How Stuff Works. 2001-05-22. Retrieved 2014-02-07.
  16. ^ "Touch sensor". Retrieved 2023-08-04.
[edit]
  • Interfacing Matrix Keypad to 8051 Controller
